产品名称：度目生产安全分析盒 EM-4S
产品型号：DMB2040P
Zynq UltraScale+MPSoc ZU5EV, Quad Cortex-A53 1.5GHz
DDR4, 8GB, 64bit
eMMC, 32GB
TF Card slot, 32GB, max support 128GB
QSPI Flash, 64MB
Support USB Camera(UVC)
BT1120 Camera
MIPI CSI Camera
IPC Camera
mini DisplayPort Interface
USB3.0x4
Gigabit Ethernet x1
mini PCIE x1
support security solution
JTAG, UART
GPIOx12, 12V, 5V, 3.3V, GND
12V DC @3A
Linux 4.14.0
Ubuntu 18.04.5
2.4 TOPS
120mm x 100mm x 50mm
主机×1
壁装支架×1
电源适配器×1
串口线×1
插头×4
螺丝包×1
产品说明手册×1
合格证×1
